Composition
Name and Function of Each Section
COLOR DOME CAMERACOLOR DOME CAMERA User’s ManualUser’s Manual
1110
Lens Rotation(3-axis)
Lens Rotation(3-axis) Guide
The lens can be adjusted ±175˚ horizontally and ±80˚ (tele) vertically.
When adjusting the lens angle, rotate the lens rotation together with rotation guide.
Rotation(3-axis) Lock
Focus Handle
To provide for accurate focusing of an object within the lens field of view.
1. SID-450
2. Instruction Manual
3. M4 Tapping Screws 4EA
4. M4 Machine Screws 4EA
5. Adapter plate
