Samsung SMT-3231

To Next Page

To Previous Page

Unit: mm (inches)

Model name VESA screw hole

specs (A * B) in

millimeters

Standard Screw Quantity

SMT-3231

200 × 200 / 7.9 × 7.9 M6

SMT-4031

―

Do not install your Wall Mount Kit while your product is turned on. It may result in personal injury due to electric shock.
