Samsung SPD-3000 User Manual

SPEED DOME CAMERASPEED DOME CAMERA User’s ManualUser’s Manual
1110
Function Setup Switch
1. Half/Full 2.3.4.5. RS-485/422 Terminal Setting
6. RS-485/422 Communication 7. Factory setting 8. RS-232
Controller Connection Input
1. RXD+ 2. RXD- 3. TXD+ 4. TXD- 5. GND 6. TX 7. RX
ID Setup Switch
Alarm Connection Input
1. IN1 2. IN2 3. GND 4. IN3 5. IN4 6. GND
7. COM1 8. 1N.C 9. 1N.O 10. COM2 11. 2N.C 12. 2N.O
Protocol Selection Switch
AC 24V Input
Part Names and Functions
Power Switch
Power ON/OFF (Factory Setting: OFF)
Body Camera Holder
