Specifications
General
General
Model Name SyncMaster 400UXn
LCD Panel
Size 40 " Diagonal (101 cm)
Display area 885.168 mm (H) X 497.664 mm (V)
Pixel Pitch 0.648 mm (H) X 0.648 mm (V)
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56 ~ 85 Hz
Display Color
16.7 M
Resolution
Optimum resolution 1360 x 768 @ 60 Hz depends on graphics card used
Maximum resolution 1360 x 768 @ 60 Hz
Input Signal, Terminated
RGB Analog, DVI Compliant Digital RGB
0.7 Vp-p ±5 %
Separate H/V sync, Composite, SOG(Option)
TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)
Maximum Pixel Clock
140MHz (Analog,Digital)
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz
Signal Cable
15pin-to-15pin D-sub cable, Detachable
DVI-D to DVI-D connector, Detachable (Sold separately)
Dimensions (W x H x D) / Weight
914 x 118 x 526 mm / 35.9 x 4.6 x 20.7 inch (Without Stand)
914 x 311 x 585 mm / 35.9 x 12.2 x 23.0 inch (With Stand) / 22.5 kg / 49.6 lbs
VESA Mounting Interface
600 x 400 mm
