State Normal Op-
eration
Power saving
mode
Power off Power off
(Power
Swich)
(Typical)
Note
• The actual power consumption may be different from the indicated power consumption above if
the system conditions or settings are changed.
• To stop any power consumption, turn off the switch or disconnect the power cable on the back. Be
sure to disconnect the power if you intend to stay away from home for many hours.
• If you connect a network box (sold separately), the LFD will no longer be in compliance with
Energy Star 5.0.
Preset Timing Modes
If the signal transferred from the computer is the same as the following Preset Timing Modes, the
screen will be adjusted automatically. However, if the signal differs, the screen may go blank while
the power LED is on. Refer to the video card manual and adjusts the screen as follows.
Display Mode
Horizontal
Frequency
(kHz)
Vertical Fre-
quency (Hz)
Pixel Clock
(MHz)
Sync Polarity
(H/V)
IBM, 640 x 350 31.469 70.086 25.175 +/-
IBM, 640 x 480 31.469 59.940 25.175 -/-
IBM, 720 x 400 31.469 70.087 28.322 -/+
MAC, 640 x 480 35.000 66.667 30.240 -/-
MAC, 832 x 624 49.726 74.551 57.284 -/-
MAC, 1152 x 870 68.681 75.062 100.000 -/-
VESA, 640 x 480 37.861 72.809 31.500 -/-
VESA, 640 x 480 37.500 75.000 31.500 -/-
VESA, 800 x 600 35.156 56.250 36.000 +/+
VESA, 800 x 600 37.879 60.317 40.000 +/+
VESA, 800 x 600 48.077 72.188 50.000 +/+
VESA, 800 x 600 46.875 75.000 49.500 +/+
VESA, 848 x 480 31.020 60.000 33.750 +/+
Specifications
PowerSaver
State Normal Op- Power saving Power off Power off
eration mode
(Power
Swich)
Power Indicator On Blinking Amber Off
Power Consumption 225 Watts 1 Watts 1 Watts 0 Watts
