C A M E R A S E TU P 1
- - - - - - - - - - - - - - - - - - -- - - - - - - - - -
F O C U S M O D E
C O L O U R
< W H I T E B A L A N C E >
< A E M O D E >
B A C K
E X I T
D I G I T A L Z O O M
D O M E C A M E R A S E T U P
- - - - - - - - - - - - - - - - - - -- - - - - - - - - -
< C A M E R A S E T U P 1 >
< M O T I O N S E T U P >
< P R E S E T S E T U P >
< S C A N S E T U P >
< P A T T E R N S E T U P >
B A C K
E X I T
< C A M E R A S E T U P 2 >
< G R O U P S E T U P >
< S C H E D U L E S E T U P >
From the main menu, use the joystick to
highlight DOME CAMERA SETUP and key:
NEAR
<CAMERA SETUP1>,
- setup of specific camera module features.
<MOTION SETUP> - setup of the pan / tilt /
zoom operation of the speed dome, park
action configuration, and configuration of the
alarm inputs.
<PRESET SETUP> - full management and
programming of individual presets.
<SCAN SETUP> - full management and
programming of SCAN functions.
<PATTERN SETUP> - full management and
programming of pattern tours.
Highlight the setup menu required and key:
NEAR
Remember: A menu item surrounded by
brackets shows it has a sub menu.
<CAMERA SETUP2>
<GROUP SETUP> - full management and
programming of group functions.
<SCHEDULE SETUP> - full management and
programming of Schedule.
From the dome camera setup menu, use the
joystick to highlight CAMERA SETUP1 and
key: NEAR
FOCUS MODE
MANUAL - the operator must focus the
camera manually using the NEAR and FAR
keys.
SEMIAUTO - the camera automatically
focuses during normal PTZ movement but
preset focus information is stored when a
preset is programmed and recalled each time
the preset is called
AUTO - the module auto focuses continually
COLOUR (ON/OFF) - switches the module
between colour and b/w mode
<WHITE BALANCE> - sub menu to change
the white balance settings
<AE MODE> - sub menu to change the auto
exposure settings
DIGITAL ZOOM (ON / OFF) - disables or
enables the 10x digital zoom. When disabled,
the maximum zoom level is 36x (optical).
Dome camera setup
Camera setup1
8
Privacy zone
Edit zone
P R I VA C Y Z O N E
- - - -- - - - - - - -- - - - - - - - - - - - - - - - -
Z O N E NO .
Z O N E DI S P L A Y
C L E AR Z O N E
< E D IT Z O N E >
B A C K
E D I T Z O N E 1
- - - - - - - - - - - - - - - - - - -- - - - - - - - - -
M O V E T O T A R G E T P O S I T I O N
[ N E A R : S E L E C T / F A R : C AN C E L ]
E D I T Z O N E 1
- - - - - - - - - - - - - - - - - - -- - - - - - - - - -
[ L / R : A D J U S T Z O N E W I D T H ]
[ U / D : A D J U S T Z O N E H E I G H T]
[ N E A R : S A V E / F A R : C A N C EL ]
From the display setup menu, use the joystick
to highlight PRIVACY ZONE and key: NEAR
ZONE NO. (1-8) - shows the privacy zone
currently being modified.
DISPLAY - determines whether the privacy
zone is displayed during normal operation.
<EDIT ZONE> - allows the operator to define
the privacy zone.
Highlight the item to modify and key: NEAR
Use the joystick to change the setting and key:
NEAR to save or: FAR to cancel.
From the privacy zone menu, use the joystick
to highlight EDIT ZONE and key: NEAR
Use the joystick to move the speed dome to
the approximate position and zoom level for
the privacy zone and key: NEAR to select or
FAR to cancel and return to the privacy zone
menu.
1
O F F
C A N C E L
O F F
A U T O
O N
Move the joystick left and right to finely adjust
the width of the privacy zone and up and down
to finely adjust the height.
To save the privacy zone, key: NEAR or key:
FAR to cancel.
