Samsung VRF DVM S2 - Outdoor Unit Specifications - Piping and Dimensions; Piping, Wiring, Refrigerant, Sound, and Dimensions (10-14 HP)

AM100AXVDGH/EU AM120AXVDGH/EU AM140AXVDGH/EU
- - -
- - -
- - -
- - -
Piping length (ODU-IDU)
Max. [Equiv.] m
200[220] 200[220] 200[220]
Piping length
(1st Branch-IDU)
Max. m 90 90 90
Total piping length
(System)
Max. m 1,000 1,000 1,000
Level difference
(ODU in highest position)
Max. m 110 110 110
Level difference
(IDU in highest position)
Max. m 110 110 110
Level difference
(IDU-IDU)
Max. m 50 50 50
Min. ㎟
0.75 0.75 0.75
Remark -
F1, F2 F1, F2 F1, F2
-
Both indoor and outdoor
unit
Both indoor and outdoor
unit
Both indoor and outdoor
unit
-
R410A R410A R410A
kg
5.5 7.0 7.0
tCO
2
e 11.48 14.62 14.62
Cooling dB(A)
56 61 63
Heating dB(A)
60 63 65
dB(A)
78 81 85
kg
185 205 207
kg
199 219 221
㎜ 930 x 1,695 x 765 930 x 1,695 x 765 930 x 1,695 x 765
㎜ 998 x 1,887 x 829 998 x 1,887 x 829 998 x 1,887 x 829
℃
-5 ~ 50 -5 ~ 50 -5 ~ 50
℃
-25 ~ 24 -25 ~ 24 -25 ~ 24
Sound Pressure
External
Dimension
Model Name
Outdoor unit module 1
Outdoor unit module 2
Outdoor unit module 3
Outdoor unit module 4
Operating
Temp. Range
Piping
Connections
Wiring
connections
Transmission
Cable
Refrigerant
Factory Charging
Net Dimensions (WxHxD)
Shipping Dimensions (WxHxD)
Cooling
Heating
Shipping Weight
Power supply intake
Type
Sound Power
Net Weight
Sound
Essential
2. Specification
NOTE
• Specification may be subject to change without prior notice.
• Specification comply with EN14825 and Eurovent test condition
1) Performances are based on the following test conditions.
- Cooling : Indoor temperature 27°CDB, 19°CWB, Outdoor temperature 35°CDB, 24°CWB
- Heating : Indoor temperature 20°CDB, 15°CWB, Outdoor temperature 7°CDB, 6°CWB
- Equivalent refrigerant pipe length 5m, Level differences 0m
- Refer to EUROVENT website(www.eurovent-certification.com) for other indoor unit combination and more detail test conditions.
2) Performance of Multiple Module Outdoor unit is weighted average of Single Module outdoor units.
3) Allowed combination ratio of the total rated indoor unit capacity over the rated outdoor unit capacity is 50~130%.
4) Sound pressure level is obtained in an anechoic room.
- Sound pressure level is a relative value, depending on the distance and acoustic environment.
- Sound pressure level may differ depending on operation condition.
- dBA = A-weighted sound pressure level
- Reference acoustic pressure 0 dB = 20uPa
5) Sound power level is an absolute value that a sound source generates.
- dBA = A-weighted sound power level
- Reference power : 1pW
- Measured according to ISO 3741
6) Sound values of multi combination are theoretical values based on sound results of individual installed units.
7) These products contain R410A (GWP=2,088) which is fluorinated greenhouse gas.
8) If outdoor unit is located in a higher position than indoor unit, level difference is 110m or under.
(If the level difference is higher than 50m, make a decision by PDM kit installation Guide software whether the PDM kit should be installed or not.)
- PDM kit: Pressure Drop Modulation kit
When the outdoor unit is below the indoor unit & the level differences are 40m or more, contact your local dealer for more information.
9) In case you want to know more information regarding capacity and correction, please refer to capacity table TDB on pvi.samsung.com site.
10) Recommended combination
* Ducted * Non-ducted
Capacity Indoor Units Capacity Indoor Units
18HP AM056ANHPKH×4 + AM071ANHPKH×4
10HP AM071ANHPKH×4
12HP AM056ANHPKH×6
14HP AM056ANHPKH×1 + AM071ANHPKH×5
16HP AM056ANHPKH×2 + AM090ANHPKH×4
Capacity Indoor Units Capacity Indoor Units
18HP
10HP
12HP
14HP
16HP
AM056AN4PKH×2 + AM090AN4PKH×2
AM028AN4PKH×2 + AM056AN4PKH×2 + AM090AN4PKH×2
AM028AN4PKH + AM045AN4PKH + AM056AN4PKH +
AM071AN4PKH + AM090AN4PKH + AM128AN4PKH
AM028AN4PKH+ AM045AN4PKH
+ AM090AN4PKH×3 +
AM128AN4PKH
AM028AN4PKH + AM036AN4PKH + AM045AN4PKH +
AM056AN4PKH×2 + AM090AN4PKH×2 +
AM128AN4PKH
