Samsung VRF DVM S2 - Outdoor Unit Specifications - Components; Casing, Heat Exchanger, Compressor, Fan, and Piping (16-20 HP)

AM160AXVDGH/EU AM180AXVDGH/EU AM200AXVDGH1EU
- - AM100AXVDGH/EU
- - AM100AXVDGH/EU
- - -
- - -
Ø, #, V, Hz 3, 4, 380-415, 50 3, 4, 380-415, 50 3, 4, 380-415, 50
- HEAT PUMP HEAT PUMP HEAT PUMP
HP 16 18 20
Cooling(Rated) kW 45.0 50.4 56.0
Heating(Rated) kW 45.0 50.4 56.0
Heating(Max) kW 50.4 56.7 63.0
EA 29 32 36
Min. kW 22.5 25.2 28.0
Max.
kW 58.5 65.5 72.8
Cooling(Rated) A 31.04 37.61 41.00
Heating(Rated) A 22.38 24.75 28.68
Cooling(Rated) A 31.04 37.25 33.96
Heating(Rated) A 21.56 24.91 26.76
Minimum Ssc MVA 5.2 6.3 7.4
MCA A 32.0 39.2 46.0
MFA A 40 50 63
SEER W/W 6.30 5.90 -
SCOP
W/W 4.20 4.10 -
ŋs.c % 249 233 -
ŋs.h
% 165 161 -
SEER W/W 6.63 6.19 -
SCOP
W/W 4.09 4.04 -
ŋs.c % 262.2 244.6 -
ŋs.h
% 160.6 158.6 -
kW 24 26.5 32.6
Body - GI Steel Plate GI Steel Plate GI Steel Plate
Base - GI Steel Plate GI Steel Plate GI Steel Plate
- Fin & Tube Fin & Tube Fin & Tube
Fin - Al Al Al
Tube - Cu Cu Cu
- Anti-corrosion Anti-corrosion Anti-corrosion
-
Inverter Scroll x 1 Inverter Scroll x 1 Inverter Scroll x 2
kW x n
8.93 x 1 8.93 x 1 (6.67 x 1) x 2
- DS4GM7090FV* x 1 DS4GM7090FV* x 1 (DS4GR7066FV* x 1) x 2
Type -
PVE PVE PVE
Initial charge cc x n 1,400 x 1 1,400 x 1 (1,100 x 1) x 2
-
Propeller Propeller Propeller
-
Top Top Top
EA
2 2 2
㎥/min
303 324 167 x 2
l/s 5,052 5,401 2,779 x 2
㎜Aq
11 11 11
Pa
110 110 110
-
BLDC Motor BLDC Motor BLDC Motor
W x n
620 x 2 620 x 2 (630 x 1) x 2
Type
Braze connection Braze connection Braze connection
Φ, ㎜ (inch)
12.70 (1/2) 15.88 (5/8) 15.88 (5/8)
Type
Braze connection Braze connection Braze connection
Φ, ㎜ (inch)
28.58 (1-1/8) 28.58 (1-1/8) 28.58 (1-1/8)
-
Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Discharge direction
Quantity
Air Flow Rate
Type
Fin Treatment
Type
Output
Compressor
Model Name
Oil
Fan
Type
External Static
Pressure
Max.
Fan Motor
Output
Maximum number of connectable indoor units
Total capacity of the connected Indoor
Units
Current Input
(Ducted)
Type
Material
Pdesignh
Casing
Material
Heat
Exchanger
Power Supply
Mode
Performance
HP
Capacity
Model Name
Outdoor unit module 1
Outdoor unit module 2
Outdoor unit module 3
Outdoor unit module 4
Current
Current Input
(Non-Ducted)
Current
Efficiency
Ducted
Non_Ducted
Piping
Connections
Liquid Pipe
Gas Pipe
Heat Insulation
Essential
2. Specification
