5. Center of Gravity
Outdoor unit
A B
C
Model A B C
Unit: mm (inches)
AM120AXVDGH/EU
AM140AXVDGH/EU
351 [13 - 13/16] 461 [18 - 1/8] 694 [27 - 5/16]
