5. Center of Gravity
Outdoor unit
C
A
Foundation bolt hole
B
Model A B C
Unit: mm (inches)
AM160AXVDGH/EU
AM180AXVDGH/EU
345[13 - 9/16]
502[19 - 3/4] 719[28 - 5/16]
