15
Model : WF457AR*
The Demo Mode of the WF457AR* model is only for Wash Mode.
- Demo mode-Wash Mode is entered when press the ‘9’ button in the Service Mode.
- If the Start/Pause button is pressed in WASH Mode, the door is locked (door Lock) and the motor
rotates left and right at 45 RPM in a 7 sec on and 3-sec o cycle.
- WASH mode continues up to ve (5) minutes once started. After the ve (5) minutes have
elapsed, back to the initial Demo mode-Wash Mode.
- If the Start/Pause button is pressed during a WASH mode operation, back to the initial Demo
mode-Wash Mode.
Connecting to a hidden AP (WF457AR*)
Proposed hidden AP specications
- The product can only connect to a hidden AP when it is in Shop Demo Mode.
- After the connection is established, even if the connection is disconnected because the product
is unplugged or the AP is turned o, the connection is automatically restored when the product
is plugged in again or the AP is turned on.
- AP name: The full name is displayed in the same way as an existing AP.
TROUBLE SHOOTING
To avoid risk of electrical shock, personal injury or death; disconnect power to washer
before servicing, unless testing requires power.
WARNING
Enter Shop Demo Mode
(Tap 1 2 1 2 1)
The Hidden AP button appears in the
Network menu.
The connection information input screen
appears.
If an encryption method is selected, the
password input box appears.
Tap to move to the AP
name input screen.
Tap to move to the
password input screen.
(Techsheet)WF457AR-03152A_EN_20120404.indd 15 2012-04-04 �� 12:12:29
