Samsung X22 - Left View 6

36
Left View
3 Fan Vents
Theinternalheatofthecomputerisemittedthroughthese
holes.
Caution
Iftheventsareblockedthecomputermayoverheat.
Avoidblockingtheventsasthismaybedangerous.
4 Wired LAN Port
ConnecttheEthernetcabletothisport. p.89
1 DC Jack
AjacktoconnecttheACadapterthatsuppliespowerto
thecomputer.
8 PCI ExpressCard Slot
InstallthePCIExpresscard
intothisslot.
6
Digital Video/Audio Port (HDMI)
YoucanconnectanHDMIcabletothisport.
Usingthisport,youcanenjoydigitalvideoand
audioontheTV.
5 Monitor Port
Aportusedtoconnectamonitor,TVorprojector
supportinga15pinD-SUBinterface.
p.57
2 USB Port
YoucanconnectUSBdevicestotheUSBportsuchasakeyboard/mouse,digitalcamera,etc.
7 Multi Card Slot
AcardslotthatsupportsMemoryStick,
MemoryStickPro,SDCard,MMC,MMC
PlusandxDcards.
p.53
