Samwon Tech ST590 User Manual

Ex) There are +2℃ in 25℃, -1℃ in 50℃, +3℃ in 75℃ as temperature deviation in measuring
actual temperature in range from 0℃ to 100℃, and try to take a Piece Bias, each Bias set
value are shown as belows(RL=0℃, BSP1=25℃, BSP2=50℃, BSP3=75℃, RH=100℃)
BS0=0℃, BS1=-2℃, BS2=+1℃, BS3=-3℃, BS4=0℃
Temperature Bias Value = Temperature after Bias - Actual Temperature
Temperature in 600℃(P) after Bias
BS3 - BS2
BSP3 - BSP2
P = 600 + (600-BPS2) X
+ BS2
Actual
Temperature
Temperature
after Piece Bias
BS0=0
BS1=10
BS2=10
BS3=50
BS4=0
BSP1=100 BSP2=500 BSP3=800RL=0 RH=1000
600℃
P
:Actual
Temperature
after Bias
BS0
RL
BSP3 RHBSP1 BSP2
Actual Temperature
Temperature
after Bias
BS1
BS2
BS3
BS4
