7.1 Dimension and Panel Cutout
96
96
91.6
99.611.4
91.6
107.5
(PANEL Thickness)
1mm~10mm
120
92
120
+0.6
0
92
+0.6
0
96XN-4
N : the Number of Unit
+2
0
92
+0.6
0
* In case of installing multiple units.
