PID SET  SET KEY
4.4.10 PID SET
(Figure 11 : PID Group)
TEMP.RP1, RP2 : Boundary value on temperature span for PID
zone
HUMI.RP : Boundary value on humidity span for PID zone
T.P/T,I/T.D/H.P/H.I/H.D : Temperature/Humidity P, I, D value for
PID 1
T(H)OH, T(H)OL : High/low value for temperature/humidity for MV
T.P / T.I / T.D : Temperature P, I, D value for PID 6
TOH, TOL : High/low value for temperature for MV
…
…
T.RP2
6
5
RL
TEMP only
RH
T.RP1
When use TEMP & HUMI
1
24
3
DRY.L
H.RP
DRY.H
(0.0)
(100.0)
