4. D-REGISTER
D-Register Range Group Description Read Write
D-Register is group of data which can using with communication all of TEMI 300s condition. Each group
has 100 registers and these are classified as follows;
D0001 ~ D0099 PROCESS BASIC PROCESS DISPLAY O ×
D0100 ~ D0199 FUNCTION OPERATION INFO DISPLAY O O
D0200 ~ D0299 RESERVATION TIME & RESERVATION O △
D0300 ~ D0399 IS INNER SIGNAL O O
D0400 ~ D0499 ALARM ALARM O O
D0500 ~ D0599 TEMP_PID TEMP P.I.D O O
D0600 ~ D0699 HUMI_PID HUMI P.I.D O O
D0700 ~ D0799 COMM COMMUNICATION O ×
D0800 ~ D0899 OUTPUT CONTROL OUTPUT O O
D0900 ~ D0999 IINPUT INPUT O O
D1000 ~ D1099 PROGRAM PROGRAM PATTERN O O
D1100 ~ D1199 PROG_INFO1 SEGMENT TEMP SP O O
D1200 ~ D1299 PROG_INFO2 SEGMENT HUMI SP O O
D1300 ~ D1399 PROG_INFO3 SEGMENT TIME SET O O
D1400 ~ D1499 PROG_INFO4 SEGMENT TIME SIGNAL1 O O
D1500 ~ D1599 PROG_INFO5 SEGMENT TIME SIGNAL2 O O
D1600 ~ D1699 PROG_INFO6 SEGMENT TIME SIGNAL3 O O
D1700 ~ D1799 ON/OFF ON/OFF SIGNAL O O
Each D-Registers are consisted hexadecimal 4charater(2-Byte)
