■ Setting IS D-Register
D-Register Symbol Description
■ Setting ALARM D-Register
IS & ALARM group is consisted Inner D-Register for Signal & Alarm setting
4.4 IS/ALARM
D0305 IS1_BAND IS1 RANGE DIRECTION
D0306 IS1_KIND IS1 RUNNING ITEM
D0307 IS1_HIGH IS1 RANGE HIGH
D0308 IS1_LOW IS1 RANGE LOW
D0309 IS1_DELAY_TM IS1 DELAY TIME
.
.
.
.
.
.
.
.
.
D0330 IS6_BAND IS6 RANGE DIRECTION
D0331 IS6_KIND IS6 RUNNING ITEM
D0332 IS6_HIGH IS6 RANGE HIGH
D0333 IS6_LOW IS6 RANGE LOW
D0334 IS6_DELAY_TM IS6 DELAY TIME
D-Register Symbol Description
D0400 AL1_ITEM ALARM 1 ADAPT POINT
. . . . . . . . .
D0403 AL4_ITEM ALARM 4 ADAPT POINT
D0405 AL1_KIND ALARM 1 ITEM
. . . . . . . . .
D0408 AL4_KIND ALARM 4 ITEM
D0410 AL1_POINT ALARM 1 POINT
. . . . . . . . .
D0413 AL4_POINT ALARM 4 POINT
D0415 AL1_HYS ALARM 1 HYSTERESIS
. . . . . . . . .
D0418 AL4_HYS ALARM 4 HYSTERESIS
D0420 AL1_DELAY_TM ALARM 1 DELAY TIME
. . . . . . . . .
D0423 AL4_DELAY_TM ALARM 4 DELAY TIME
