■ Setting PID D-Register
D-Register Symbol
PID GROUP is consisted D-Register for setting PID
4.5 PID
D0500 TEMP_PB1
.
.
.
.
.
.
D0501 TEMP_TI1
D0502 TEMP_TD1
D0503 TEMP_OH1
D0504 TEMP_OL1
D0505 TEMP_MR1
D0530 TEMP_PB6
D0531 TEMP_TI6
D0532 TEMP_TD6
D0533 TEMP_OH6
D0534 TEMP_OL6
D0535 TEMP_MR6
D0500 HUMI_PB1
.
.
.
.
.
.
D0601 HUMI_TI1
D0602 HUMI_TD1
D0603 HUMI_OH1
D0604 HUMI_OL1
D0605 HUMI_MR1
D0630 HUMI_PB6
D0631 HUMI_TI6
D0632 HUMI_TD6
D0633 HUMI_OH6
D0634 HUMI_OL6
D0635 HUMI_MR6
Description
PROPORTIONAL OPERATION TIME FOR TEMP PID1 CONTROL
.
.
.
INTEGRATION TIME FOR TEMP PID1 CONTROL
DERIVATION TIME FOR TEMP PID1 CONTROL
THE HIGH RANGE OF TEMP PID 1
THE LOW RANGE OF TEMP PID 1
MANUAL SET VALUE APPLY TO TEMP PID1
PROPORTIONAL OPERATION TIME FOR TEMP PID6 CONTROL
INTEGRATION TIME FOR TEMP PID 6 CONTROL
DERIVATION TIME FOR TEMP PID 6 CONTROL
THE HIGH RANGE OF TEMP PID 6
THE LOW RANGE OF TEMP PID 6
MANUAL SET VALUE APPLY TO TEMP PID 6
PROPORTIONAL OPERATION TIME FOR TEMP PID 1 CONTROL
.
.
.
INTEGRATION TIME FOR TEMP PID 1 CONTROL
DERIVATION TIME FOR TEMP PID 1 CONTROL
THE HIGH RANGE OF TEMP PID 1
THE LOW RANGE OF TEMP PID 1
MANUAL SET VALUE APPLY TO TEMP PID 1
PROPORTIONAL OPERATION TIME FOR TEMP PID 6 CONTROL
INTEGRATION TIME FOR TEMP PID 6 CONTROL
DERIVATION TIME FOR TEMP PID 6 CONTROL
THE HIGH RANGE OF TEMP PID 6
THE LOW RANGE OF TEMP PID 6
MANUAL SET VALUE APPLY TO TEMP PID 6
