■ Setting OUTPUT D-Register
D-Register Symbol Description
OUTPUT GROUP is consisted D-Register for setting Control Output
4.6 OUTPUT
D0800 TEMP_OT TEMP OUTPUT TYPE
D0801 TEMP_DR TEMP DIRECTION
D0802 TEMP_CT TEMP CYCLE
D0803 TEMP_ARW TEMP ARW
D0806 TEMP_ATGAIN TEMP AT GAIN
D0807 TEMP_ATGAIN HUMI AT GAIN
D0810 HUMI_OT HUMI OUTPUT TYPE
D0811 HUMI_DR HUMI DIRECTION
D0812 HUMI_CT HUMI CYCLE
D0813 HUMI_ARW HUMI ARW
D0816 TEMP_RET_KIND TEMP RETRANSMISSION TYPE
D0817 TEMP_RET_RL TEMP RETRANSMISSION LOW RANGE
D0818 TEMP_RET_RH TEMP RETRANSMISSION HIGH RANGE
D0821 HUMI_RET_KIND HUMI OUTPUT TYPE
D0822 HUMI_RET_RL HUMI RETRANSMISSION LOW RANGE
D0823 HUMI_RET_RH HUMI RETRANSMISSION HIGH RANGE
D0839 DOCON_IS1 INNER SIGNAL1 CONTACT OUTPUT
. . . . . . . . .
D0845 DOCON_IS6 INNER SIGNAL6 CONTACT OUTPUT
D0846 DOCON_TS1 TIME SIGNAL1 CONTACT OUTPUT
D0847 DOCON_TS2 TIME SIGNAL2 CONTACT OUTPUT
D0848 DOCON_AL1 ALARM SIGNAL1 CONTACT OUTPUT
. . . . . . . . .
D0851 DOCON_AL4 ALARM SIGNAL4 CONTACT OUTPUT
D0852 DOCON_TRUN TEMP RUN CONTACT OUTPUT
D0853 DOCON_HRUN HUMI RUN CONTACT OUTPUT
D0854 DOCON_T1 T1 SIGNAL1 CONTACT OUTPUT
. . . . . . . . .
D0857 DOCON_T4 T4 SIGNAL4 CONTACT OUTPUT
