18
[Fig. 3-10] Stationary operation #3 operation screen
23
1
(5) Stationary operation #3 operation screen
●Theabovescreenistodisplaythemeasuringdate,settingdataofTemperatureandHumidity.Thedirectionofgraphishorizontal.
●()checkboxsetsY/Nfordatadisplay.
●Possibletosaverecordingvaluesintotheinternalmemoryusingthisbutton
●Thesaveddataintotheinternalmemoryarepreservedwhentheelectricpoweris"ON/OFF"
●Referto[6-2Presentvalue(PV)graphview]
①
②
③
Itdisplaysthemeasuringdata,settingdataofcurrentlyoperated
TemperatureandHumidity.
Itdisplaysthecapacityofinternalmemory.
●
 About90daysofsavingisavailablewhenthesamplingtimeissetin1second.
Itisabuttontosavethemeasuringdata,settingdataofcurrently
recordedTemperatureandHumidityintotheInternalmemory.
[Fig.3-11]Stationaryoperation#3operationscreen(UserKey)
