25
(5) Program operation #3 operation screen
[Fig. 3-21] Program operation #3 operation screen
●Theabovescreenistodisplaythemeasuringdate,settingdataofTemperatureandHumidity.Thedirectionofgraphishorizontal.
●()checkboxsetsY/Nfordatadisplay.
●Possibletosaverecordingvaluesintotheinternalmemoryusingthisbutton
●Thesaveddataintotheinternalmemoryarepreservedwhentheelectricpoweris"ON/OFF"
●Referto[6-2Presentvalue(PV)graphview]
23
1
[Fig.3-22]Programoperation#3operationscreen(UserKey)
①
②
③
Itdisplaysthemeasuringdata,settingdataofcurrentlyoperated
TemperatureandHumidity.
Itdisplaysthecapacityofinternalmemory.
●
 About90daysofsavingisavailablewhenthesamplingtimeissetin1second.
Itisabuttontosavethemeasuringdata,settingdataofcurrently
recordedTemperatureandHumidityintotheInternalmemory.
03. Operation state screen setting
