DIMENSIONS AND WEIGHTS
Section Dimensions and Weights
System
Dimensions
L
D
H (in.)11
11
Number of
Sections
Approximate System Weight (lbs.)
Total System
Weight (lbs.)
KVAR Voltage Stages
Control
Section
Capacitor
Section 1
Capacitor
Section 2
500
480 3 87
37
121 1 6,000 — — 6,000
600 3 87
37
121 1 5,500 — — 5,500
625
480 3 87
37
121 1 6,500 — — 6,500
600 3 87
37
121 1 6,000 — — 6,000
750
480 3 87
37
121 1 7,500 — — 7,500
600 3 87 37 121 1 7,000 — — 7,000
1000
480 3 87
37
121 1 8,500 — — 8,500
600 3 87
37
121 1 8,000 — — 8,000
1250
480
3 174
37
121 2 7,000 2,500 — 9,500
4 174
37
121 2 7,000 2,500 — 9,500
600
3 87
37
121 1 9,000 — — 9,000
4 87 37 121 1 9,000 — — 9,000
1500
480
3 174 37 121 2 7,500 3,000 — 10,500
4 174 37 121 2 7,500 3,000 — 10,500
600
3 87 37 121 1 9,500 — — 9,500
4 174 37 121 2 7,000 2,500 — 9,500
2000
480
3 174 37 121 2 8,000 3,500 — 11,500
4 174 37 121 2 8,000 3,500 — 11,500
600
3 174 37 121 2 7,500 3,000 — 10,500
4 174 37 121 2 7,500 3,000 — 10,500
2500
480
3 261 37 121 3 8,500 4,000 3,500 16,000
4 261 37 121 3 8,500 4,000 3,500 16,000
600
3 174 37 121 2 8,000 3,500 — 11,500
4 174 37 121 2 8,000 3,500 — 11,500
3000
480
3 261 37 121 3 9,000 4,000 3,500 16,500
4 261 37 121 3 9,000 4,000 3,500 16,500
600
3 174 37 121 2 8,500 3,500 — 12,000
4 174 37 121 2 8,500 3,500 — 12,000
4000
480
3 261 37 121 3 9,500 4,000 3,500 17,000
4 261 37 121 3 9,500 4,000 3,500 17,000
600
3 261 37 121 3 9,000 4,000 3,000 16,000
4 261 37 121 3 9,000 4,000 3,000 16,000
5000
480
3 261 37 121 3 10,000 4,000 4,000 18,000
4 261 37 121 3 10,000 4,000 4,000 18,000
600
3 261 37 121 3 9,500 4,000 3,500 17,000
4 261 37 121 3 9,500 4,000 3,500 17,000
6000 600
3 261 37 121 3 10,000 4,000 4,000 18,000
4 261 37 121 3 10,000 4,000 4,000 18,000
1 Height dimension includes outdoor fan. Height dimension with indoor fan is 108 inches. Height dimension with fan housing removed is 102 inches.
