4 S&C Instruction Sheet 461-508LD
Specications
TripSaver II Cutout-Mounted Recloser Control
Module Integration
Two electronic TripSaver II Cutout-Mounted Recloser
control modules (model numbers TSII-CONTRL5 and
TSII-CONTRL6) can integrate into the host self-powered
cutout-mounted, electronically controlled single-phase
recloser. The recloser uses a vacuum fault interrupter
technology and is offered in system class voltage ratings
of 15 kV and 25 kV.
The control module is an integral part of the TripSaver
II recloser, and S&C will install it at the factory. End-
users cannot do the installation themselves. Regardless
of the model, the control module resides in the TripSaver
II Cutout-Mounted Recloser’s housing, and each model’s
functions remain the same for all recloser configurations.
The control module processes all electrical functions
required for the proper operation of the TripSaver II
Cutout-Mounted Recloser.
Aside from its primary functions, the control module
can be wirelessly accessed by following the IEEE 802.15.4
protocol for performing maintenance. The control module
includes a radio transceiver, an antenna, and software.
Information regarding the 2.4-GHz radio is provided in
Table 1 . The communication protocol remains unaltered in
all TripSaver II Cutout-Mounted Recloser configurations.
Table 1. Details of the TripSaver II Cutout-Mounted Recloser Control Module
Applicant S&C Electric Company
Brand Name TripSaver® II Cutout-Mounted Recloser
Product Model Name TripSaver II Control 5 and TripSaver II Control 6
Product Model Number TSII-CONTRL5 and TSII-CONTRL6
FCC Identifier U3D-TSIICONTRL6
IC Identifier 5349C-TSIICONTRL6
Dimension 6.53 in. (16.6 cm) x 5.198 in. (13.2 cm) x 2.98 in. (7.6 cm)
Weight 20 oz. (567 g) for TSII-CONTRL6 and 17.6 oz. (499 g) for TSII-CONTRL5
Technologies Supported by the Equipment Bluetooth Low Energy (Bluetooth 5), IEEE 802.15. 4 (Zigbee), Thread
Transmission Speed 250 kbps
Type of Transmission Digital Transmission System (DTS)
Rated RF Output 10.5 dBm (11.22 mW)
Frequency Range 2405 – 2480 MHz
Type of Modulation/Data Rate GFSK / 1 Mbit/s
O-QPSK / <200 kbps
Bandwidth 5 MHz
Number of Channel(s) 16 (from 11 to 26)
Antenna(s) and Gain PCB antenna, Gain: 3dBi
CT Voltage Input CT input 230 Vac, 2 A, 50/60 Hz
J10 input 11-14.5 Vdc, 1 A
Environmental -40°C (-40°F) to +40°C (+104°F).
Manufacturer Name and Address S&C Electric Company
6601 N Ridge Blvd.
Chicago, IL 60626
