AMBER ■ Heading bug and associated data
■ GPS annunciator: MSG and WPT. Also
HOLD (Garmin only)
■ Compass rose when either the gyro or
fluxgate has failed
■ Middle marker indicator
■ Moving map waypoints
YELLOW ■ Information associated with the cross-side
NAV receiver (NAV2 if in pilot
configuration, NAV1 if in co-pilot
configuration)
■ Information associated with the cross-side
GPS bearing pointer (GPS2 when
navigating on GPS1, GPS1 when navigating
on GPS2)
■ Restricted and warning areas
MAGENTA ■ Active leg and waypoint of flight plan
■ ADF bearing pointer
BLUE ■ Outer marker indicator
PURPLE ■ MOAs
