Displaying the Deviation Bar
The small course deviation bar (or “D-bar”) display in the lower
portion of the screen is visible at all times. In addition, a larger
conventional D-bar can be displayed. This D-bar will be displayed only
under the following conditions:
■
The “DEV BAR” setting under [SHFT]>[NAV] must be
turned ON
■
The map display must be turned OFF
■
The [VUE] mode must be 360-degree view
To turn the map off, press [MAP] until “MAP OFF” appears in the
upper right portion of the screen. Note that if the WX-500
Stormscope display is turned on, “MAP OFF” will not appear even
though the map is deselected. To turn off both the map and the
Stormscope display simultaneously, press and hold the [MAP] button
for at least 1.5 seconds.
Displaying the Course Pointer
The course pointer itself can be removed from the display to allow
navigating on the courseline from your LNAV receiver. Press
[SHFT]>[NAV], then the [CRS PTR] softkey to toggle the setting
between “AUTO” and “ON”.
When set to “ON”, the course pointer is always displayed.
When set to “AUTO”, the course pointer will be turned off under the
following conditions:
■
An LNAV receiver (GPS or loran) is selected for
navigation, and
■
A waypoint or flight plan is entered, and
■
Flight plan waypoints are enabled on the current
map memory.
When NAV is selected for navigation, the course pointer is always
displayed.
3-9
3
Operational Basics
CHAPTER
