Sub-Menu Summary
The [SHFT] button accesses a sub-menu mode which provides even
more functions. The following table summarizes the sub-menu
functions:
4-20
4
Button Operations Map
CHAPTER
Button SCREEN LABEL FUNCTION PERFORMED
VUE No function performed.
WX Accesses control functions of the WX-
500 Stormscope
®
remote sensor, if
installed. Turns Stormscope
®
display
on or off, clears existing display and
allows selection of cell versus strike
mode. Also accesses sytem sub-menu
for self-test or demo mode.
No function performed.
A-B A=B Copies the current screen settings into
the inactive screen setting memory.
SYNC DTK Performs a course sync, i.e. turns the
course pointer to the direct-to source.
SHFT ESC (flashing) Cancels the SHFT function.
BRG BRG PTRS Presents source selection for both
bearing pointers.
MAP MAP Accesses map setup functions.
NAV NAV Accesses NAV functions.
Selects approach mode control
buttons for GPS, if enabeled.
Selects AUTO-SLEW, which allows the
long-range nav source to automatically
set the course pointer to the desired
track.
Controls display of the center D-bar
for the CDI and GS needles.
