Sandel SN3308 - Page 42

4-6
Button Operations Map
4
B
R
G
BRG
Turns bearing pointers on/off.
SHFT›BRG
Allows assignment of nav sources to BRG 1 & 2
pointers. Currently selected nav source is indicated by
asterisk (e.g. *AUTO*).
