5-5
5
Enhanced Moving Map Features
CHAPTER
Status Bar Item Softkey Color Map
Icon Label Setup
Page
Airports Civil CIVIL Amber 1
Military MIL Amber
Private PRIV Amber
Runway Length
3
MIN LEN - 2
Grass Surface GRASS SURFC -
Other Surface OTHER SURFC -
Airspace Class B ‘B’ Green (dashed) 3
Class C ‘C’ Green (dotted)
MOA MOA Purple (dotted) 4
Restricted RESTR Yellow (dashed)
Warning WARN Yellow (dotted)
Prohibited
1
- Red (solid) -
Intersections Enroute ENRT Amber 5
SID SIDS Amber
STAR STARS Amber
NDBs Outer Marker OM Amber 6
Low Power L PWR Amber
High Power H PWR Amber
VORs High Level HI LV Amber 7
Low Level LO LV Amber
Terminal TERM Amber
GPS Waypoints or Magenta: 8
Flight plan Waypoints and FPL ENA currently
WPTS courselines active leg;
Waypoint FPL SYM White:
symbols
2
previous or
next leg
TACAN on/off
4
Adds to VORs TACAN Amber
To Next Page
