8
Technical Specifications and Operating Limits
CHAPTER
TSO Compliance
Technical Standard Order (TSO):
TSO-C113, Airborne Multipurpose
Electronic Displays
Software Certification:
RTCA/DO-178B, Level C - Hazardous
Environmental Category:
DO-160C: F1CANBMXXXXXXZBABBWA/ZXXX
DO-160D: XXXXXXXXXXXXXXXXX(E/F-2)XX
Physical Dimensions
Form Factor:
3ATI (ARINC 408)
Width:
3.165 in. (8.04 cm)
Height:
3.165 in. (8.04 cm)
Length:
10.65 in. (26.24 cm) overall, excluding
connectors & knobs
Weight:
2.9 lbs (1.3 Kg)
Operational Characteristics
Temperature/Altitude:
-20˚ C to +70˚ C up to 55,000 ft
Power Inputs:
11 to 33 VDC @ 3.2 Amperes maximum
13.75 VDC @ 2.5 Amperes nominal
27.5 VDC @ 1.25 Amperes nominal
8-1
