Sandel SN3308 - 360 View Illustration

A2-1
Current NAV Source
To/From
(Shown for Reference)
Selected Course
DME Distance
Bearing Pointer 1
Current A-B
Memory
Bearing Pointer 2
Current Heading
Heading Bug
Bearing Pointer 1 Source
& Bearing
Bearing Pointer 2 Source
Distance & Bearing
CDI/Lateral Deviation
Groundspeed
Selected Heading
Course Pointer
Glideslope/
Vertical Deviation
ILLUSTRATION 1 – 360 View
