S&P CADB/T-HE PRO-REG Series User Manual

14
ENGLISH
6.3. MOUNTING PROCESS OF AN ADDITIONAL SUPPLY FILTER
The heat recovery unit is supplied with the fi lters already installed.
F7 in exhaust air and M5 in supply air. In addition, it is possible to mount a second fi lter in the unit
(accessory). (For more information see section “Replacing fi lters”).
6.4. RANGE SPECIFICATIONS
D Models: without heater battery
Model Complete unit Fan Weight
(kg)
Air
connections
diameter
(mm)
Nominal
airfl ow
(m
3
/h)
Effi ciency*
(%)
Electrical
supply
Max.
abs.
power
(kW)
Maximum
current
(A)
Speed
(r.p.m.)
Maximum
current
(A)
CADB-HE D 04 PRO-REG 200 450 87 1/230V, 50Hz 0,2 2,2 3700 0,95 147
CADB-HE D 08 PRO-REG 250 800 86,4 1/230V, 50Hz 0,4 2,9 2650 1,3 183
CADB-HE D 12 PRO-REG 315 1.200 85,3 1/230V, 50Hz 0,95 3,5 2550 1,6 190
CADB-HE D 16 PRO-REG 315 1.600 85,5 1/230V, 50Hz 0,95 4,3 2845 2,0 235
CADB-HE D 21 PRO-REG 400 2.100 86,7 1/230V, 50Hz 0,9 4,7 1580 2,2 333
CADT-HE D 33 PRO-REG 400 3.300 85,9 3+N/400V, 50Hz 2,2 4,3 2600 2,0 420
CADB-HE D 40 PRO-REG 450 4.000 86,8 1/230V, 50Hz 2,5 15,1 2340 7,4 597
CADB-HE D 54 PRO-REG 500 5.400 87,1 1/230V, 50Hz 3,4 20,3 2110 10 730
* Humid efficiency referring to nominal airflow, outdoor conditions (-5ºC / 80% RH) and indoor (20ºC / 50% RH)
DC Models: with built-in hot water coil
Model Complete unit Fan Hot water coil Weight
(kg)
Air
connections
diameter
(mm)
Nominal
airfl ow
(m
3
/h)
Effi ciency*
(%)
Electrical
supply
Max.
abs.
power
(kW)
Maximum
current
(A)
Speed
(r.p.m.)
Maximum
current
(A)
Heat
power
T.water
80/60ºC
(kW)
Heat
power
T.water
50/45ºC
(kW)
CADB-HE DC 04 PRO-REG 200 450 87,0 1/230V, 50Hz 0,2 2,2 3700 0,95 2,7 1,6 149
CADB-HE DC 08 PRO-REG 250 800 86,4 1/230V, 50Hz 0,4 2,9 2650 1,3 5,1 3,1 186
CADB-HE DC 12 PRO-REG 315 1.200 85,3 1/230V, 50Hz 0,95 3,5 2550 1,6 7,1 4,3 193
CADB-HE DC 16 PRO-REG 315 1.600 85,5 1/230V, 50Hz 0,95 4,3 2845 2,0 8,6 5,3 239
CADB-HE DC 21 PRO-REG 400 2.100 86,7 1/230V, 50Hz 0,9 4,7 1580 2,2 12,6 7,8 338
CADT-HE DC 33 PRO-REG 400 3.300 85,9 3+N/400V, 50Hz 2,2 4,3 2600 2,0 18,2 11,1 427
CADB-HE DC 40 PRO-REG 450 4.000 86,8 1/230V, 50Hz 2,5 15,1 2340 7,4 23,9 14,4 606
CADB-HE DC 54 PRO-REG 500 5.400 87,1 1/230V, 50Hz 3,4 20,3 2110 10 32,1 19,5 742
* Humid efficiency referring to nominal airflow, outdoor conditions (-5ºC / 80% RH) and indoor (20ºC / 50% RH)
DI Models: with built-in electric heater battery
Model Complete unit Fan Electrical heater
battery
Weight
(kg)
Air
connections
diameter
(mm)
Nominal
airfl ow
(m
3
/h)
Effi ciency*
(%)
Electrical
supply
Max.
abs.
power
(kW)
Maximum
current
(A)
Speed
(r.p.m.)
Maximum
current
(A)
Power
(kW)
Maximum
current
(A)
CADB-HE DI 04 PRO-REG 200 450 87,0 1/230V, 50Hz 1,2 6,7 3700 0,95 1 4,5 148
CADB-HE DI 08 PRO-REG 250 800 86,4 1/230V, 50Hz 2,4 12,0 2650 1,3 2 9,1 185
CADB-HE DI 12 PRO-REG 315 1.200 85,3 1/230V, 50Hz 4,0 14,9 2550 1,6 3 11,4 192
CADB-HE DI 16 PRO-REG 315 1.600 85,5 1/230V, 50Hz 4,5 20,2 2845 2,0 3,5 15,9 237
CADB-HE DI 21 PRO-REG 400 2.100 86,7 3+N/400V, 50Hz 6,9 13,8 1580 2,2 6 9,11 336
CADT-HE DI 33 PRO-REG 400 3.300 85,9 3+N/400V, 50Hz 9,7 15,7 2600 2,0 7,5 11,4 424
CADB-HE DI 40 PRO-REG 450 4.000 86,8 3+N/400V, 50Hz 11,5 28,8 2340 7,4 9 13,7 602
CADB-HE DI 54 PRO-REG 500 5.400 87,1 3+N/400V, 50Hz 15,4 38,5 2110 10 12 18,2 737
* Humid efficiency referring to nominal airflow, outdoor conditions (-5ºC / 80% RH) and indoor (20ºC / 50% RH)
