Model HDF2/HDF50 • 8
Composite Repair Parts List
Item Part Number Description Qty
1* 031.019.156 Air Valve Assy (Aluminum Center -
see pg #10 for details) 1
031.019.010 Air Valve Assy (Cast Iron Center) 1
031.019.001 Air Valve Assy (Alum Center
SS/BRASS Sleeve Spool-High Clr) 1
031.019.004 Air Valve Assy (Alum Center
SS/BRASS Sleeve-Spool) 1
031.089.156 Air Valve Assy (Alum Center -
stroke Indicator) 1
031.089.010 Air Valve Assy (Cast Iron Center -
stroke Indicator) 1
2 070.006.170 Bushing, Intermediate
(included in item #4) 2
3 095.073.001 Pilot Valve Assy 1
4 114.002.156 Intermediate (w/ aluminum center) 1
114.002.010 Intermediate (w/ cast iron center) 1
5 115.158.080 Bracket, Leg 2
6 115.159.080 Bracket, Leg 2
7 132.002.360 Bumper, Diaphragm 2
8 135.016.162 Bushing, Plunger 2
9 170.023.330 Capscrew, Hx-Hd 7/16-14 x 1.75
(Aluminum wetted) 8
170.023.330 Capscrew, Hx-Hd 7/16-14 x 1.75
(CI and SS wetted) 16
10 170.024.330 Capscrew, Hx-Hd 7/16-14 x 1.00 8
11 170.026.330 Capscrew, Hx-Hd 3/8-16 x 3.50 2
12 170.035.330 Capscrew, Hx-Hd 7/16-14 x 1.50
(Aluminum wetted) 8
13 170.045.330 Capscrew, Hx-Hd 5/16-18 x 1.25 4
14 170.052.330 Capscrew, Hx-Hd 3/8-16 x 2.25 2
15 170.061.330 Capscrew, Hx-Hd 3/8-16 x 2.00 16
16 171.002.330 Capscrew, Socket, Fl-Hd 5/8-
11 x 1.50 (Alum/CI Wetted) 2
171.002.110 Capscrew, Socket, Fl-Hd 5/8-
11 x 1.50 (Stainless Wetted) 2
17 196.001.157 Chamber, Inner
(w/ aluminum center) Includes #35 2
196.001.010 Chamber, Inner
(w/ cast iron center) Includes #35 2
18 196.002.157NS Chamber, Outer (w/ aluminum
wetted) Includes #36,44 4
196.002.010NS Chamber, Outer (w/ cast iron
wetted) Includes #36,44 4
196.002.110NS Chamber, Outer (w/ stainless
wetted) Includes #36,44 4
19 286.007.354 Diaphragm - Santoprene 2
286.007.356 Diaphragm - Hytrel 2
286.007.360 Diaphragm - Buna 2
286.007.363 Diaphragm - FKM 2
286.007.364 Diaphragm - EPDM 2
286.007.365 Diaphragm - Neoprene 2
20 312.012.156 Elbow, Suction (w/ aluminum
wetted) includes item #44) 2
312.012.010 Elbow, Suction (w/ cast iron wetted)
includes item #44) 2
312.012.110 Elbow, Suction (w/ stainless wetted)
includes item #44) 2
21 312.013.156 Elbow, Discharge
(w/ aluminum wetted) 2
312.013.010 Elbow, Discharge
(w/ cast iron wetted) 2
312.013.110 Elbow, Discharge
(w/ stainless wetted) 2
22 338.005.360 Valve, Flap Assembly - Buna 4
338.005.363 Valve, Flap Assembly - FKM 4
338.005.364 Valve, Flap Assembly - EPDM 4
338.005.365 Valve, Flap Assembly - Neoprene 4
ATEX Compliant
LEGEND:
= Items contained within Air End Kits
= Items contianed within Wet End Kits
* Air end kit contains sleeve and spool set only, not complete air valve assembly
Note: Kits contain components specic to the material codes.
23 360.041.379 Gasket, Pilot Valve 1
24 360.048.425 Gasket, Air Valve 1
25 518.001.157 Manifold (w/ aluminum wetted) 2
518.001.010 Manifold (w/ cast iron wetted) 2
518.001.110 Manifold (w/ stainless wetted) 2
26 530.033.000 Mufer, Metal 1
27 545.007.330 Nut, Hex 7/16-14 (aluminum
wetted only) 12
28 547.002.110 Nut, Nylon Stop 1/4 x 20 8
29 560.001.360 O-ring 2
30 560.022.360 O-ring 2
31 570.001.360 Pad, Hinge - Buna 4
570.001.363 Pad, Hinge - FKM 4
570.001.364 Pad, Hinge - EPDM
(also used w/ Santoprene) 4
570.001.365 "Pad, Hinge - Neoprene (also
used with Hytrel & Urethane)" 4
32 570.009.360 Pad, Wear - Buna 2
570.009.363 Pad, Wear - FKM 2
570.009.364 Pad, Wear - EPDM (also used w/
Santoprene) 2
570.009.365 Pad, Wear - Neoprene (also
used with Hytrel & Urethane) 2
33 612.047.330 Plate, Inner Diaphragm 2
34 612.008.330 Plate, Outer Diaphragm (w/
aluminum/cast iron wetted) 2
612.096.110 Plate, Outer Diaphragm (w/
stainless wetted) 2
35 618.003.330 Plug, Pipe 1/4" NPT 2
36 618.003.330 Plug, Pipe 1/4" NPT (w/ aluminum/
cast iron wetted) 4
618.003.110 Plug, Pipe 1/4" NPT (w/ stainless
wetted) 4
37 620.011.114 Plunger, Actuator 2
38 670.005.110 Retainer, Flap Valve 4
39 675.013.360 Ring, Sealing - Buna 4
675.013.363 Ring, Sealing - FKM 4
675.013.364 Ring, Sealing - EPDM (used w/
Santoprene) 4
675.013.365 Ring, Sealing - Neoprene (used
with Hytrel & Urethane) 4
40 685.007.120 Rod, Diaphragm 1
41 720.004.360 Seal, U-Cup 2
42 722.070.360 Seat, Check Valve - Buna 4
722.070.363 Seat, Check Valve - FKM 4
722.070.364 Seat, Check Valve - EPDM
(used w/ Santoprene) 4
722.070.365 Seat, Check Valve - Neoprene
(used with Hytrel & Urethane) 4
43 770.005.330 Spacer (w/ aluminum wetted) 2
44 807.018.110 Stud, 1/4-20 (inlcuded with
item #18 & #20) 8
45 900.005.330 Washer, Lock 3/8" 20
46 900.006.330 Washer, Lock 7/16" (w/ aluminum
wetted) 16
900.006.330 Washer, Lock 7/16" (w/ cast iron
and stainless wetted) 8
47 902.003.000 Washer, Sealing 2
48 560.046.360 O-ring (w/ stainless steel wetted) 2
MODEL SPECIFIC
