15
GB
Time/Date
Channel no. / Frequency
Bitrate / Radio Mode
(DAB/DAB+)
DAB Display Modes
The station name will be displayed on the top line of the LCD display.
Every time you press the INFO button, the bottom line of the display will cycle through the
following display modes: DLS, Prg Type, Multiplex, Time/Date, Channel no. /Frequency,
Bitrate / Radio Mode (DAB/DAB+), Signal Strength.
DLS (Dynamic Label Segment)
Dynamic label segment is a scrolling message
that the broadcaster may include with their
transmissions. The message usually includes
information, such as program details etc.
Prg Type (Programme Type)
This describes the “Style” or “genre” of music
that is being broadcast e.g. “Rock” or “Classical”.
If the information is not available, the display
will show <Program Type>.
Multiplex
A multiplex is a collection of radio stations that
are bundled and transmitted on one frequency.
There are national and local multiplexes. Local
ones contain stations that are specic to that
area.
Time/Date
The broadcaster (Radio station) provides clock
and date information automatically so there’s
no need to manually set this information. In the
unlikely event that the broadcaster does not
transmit any clock information, the display will
show the incorrect time and date.
Channel no. / Frequency
The Channel no. and frequency of the
present station will be displayed, such as “11C
220.352MHz”.
Bitrate/ Radio Mode (DAB/DAB+)
The display will show the radio mode (DAB
or DAB+) and the digital audio bit rate being
received.
Signal Strength
The display will show a slide bar to indicate
the signal strength, the stronger the signal, the
longer the bar will be from left to right.
Prg Type
DLS
Multiplex
Signal Strength
