Sansui 7900Z - Page 29

4
4
}
pea cate open aE
nei
Mee”
Parts No. Stock No. Description
eTransistor
eQ1~4 07194800,1 2SC1815 Y,GR (79002)
eO3 07194700,1 2SA1015 Y,GR
e05 03059501,2 2SC945 Q,P
eiC
elCi 07237200 LA1245
eVaractor Diode :
eD1 07197200 KV1226
e@Diode
eD3, 4 03117600 182473D (79002)
5-2. F-3296 Digitally Frequency Display Circuit Board. (Stock No.
Component Side
Naw be eo a ee ee re ote
7 99002/89002D8/794mE
Parts No. Stock No.
Description
eTCt,2 12301000
eCF1 07254000
eCF2 07265100
elt 46027100
eL2 42306200
eVR1 07241300
eVR2 07241500
Parts List
Parts No. Stock No. Description
Transistor
sO51 03059500,1 2SC945 R,Q
sQ52 07194700,1 2SA1015 Y,GR
07197000,1 2SA733A R,Q
sO53 07194700,1 2SA1015 Y,GR
07197000; 1 - 2SA733A_ R,.Q
sO54 07194700,1 2SA1015 Y,GR
07197000,1 2SA733A R, Q
sO55 07194700,1 2SA1015 Y,GR
07197000,1 2SA733A R, Q
sQ56 07194700,1 2SA1015 Y,GR
- » 07197000,1 2SA733A R, Q
sQ57 07194700,1 2SA1015 Y,GR
07197000,1 2SA733A R,Q
sQ58 07194700,1 2SA1015 Y,GR
07197000,1 2SA733A R, Q
sO59 07194800,1 2SA1015 Y,GR
03059500,1 2SC945 at a
sO.60 07194800,1 2SC1815 Y,GR
03059500,1 2SC945 R, O
s061 07194700,1 2SA1015 Y,GR
07197000,1 2SA733A R,0
sO62 07194700,1 2SA1015 Y,GR
07197000,1 2SA733A R,Q
3063 07194800,1 2SC1815 Y,GR
03059500,1 2SC945 R,Q
sO64 07194800,1 2SC1815 Y,GR
03059500,1 2SC945 R,Q
e1Cc
siC51 07225100 TOD6301P
eDiode
sD51~55 03111600 1$2473D
Trimmer Capacitor 15pF
Ceramic Filter
Ceramic Filter (79002)
AM OSC Coil
AM IF Coil 455 kHz
Semi Variable Resistor 10k (B),
AM signa} adj.
Semi Variable Resistor 50k (B},
AM auto search level adj. (7900Z)
00614401 = 9900Z, 8900ZDB/00621801 = 79002)
Parts No. Stock No.
sPL51 00000100
sPL52 04007600
sPL53 04006600
sR101 07267200
sR102 07267400
sR103 07267300
<99002, 8900ZDB Only>
eTransistor
051 07194800, 1
03059500, 1
£052 07194800, 1
03059500, 1
fQ53 07194800, 1
03059500, 1
fQ54 07194800, 1
03059500, 17
oIC
fiC51 03604000
03604100
fiC52 03604000
03604100
eDiode
f051 03111600
#D52 03111600
#D53 03111600
Description
Fluorescent Display Tube
Pilot Lamp 8V 300mA
Pilot Lamp 8V 150mA
RM65.6k& x 6 (Block Resistor)
RM105.6k2Q x 10 (Block Resistor)
RM85.6k2 x 8 (Block Resistor)
2SC1815 Y,GR
2SC945 R,Q
2SC1815 Y,GR
2SC945 R,Q
28C1815 Y,GR
28C945 F,Q
2SC1815 Y,GR
28C945 R,Q
MSM4011
TC4011P
MSM4011
TC4011P
1$2473D
182473D ae
1$2473D
12
