Santint A2 - 6.3 Add Colorant; 6.4 Emptying Pump

A2 Automatic Dispenser V3.0 7
suddenly, the software shows E18 “No paint can, colorant could not be spouted out”
 Test the top cover: the machine could not be operated when the top cover is opened.
Press the emergency stop button under any suddenness.
Pressing the emergency stop button also can stop stirring.
6
6
.
.
3
3
A
A
d
d
d
d
C
C
o
o
l
l
o
o
r
r
a
a
n
n
t
t
 Before colorant is added in to canister, it must be fully mixed by stirring ruler, it is not recommended to mix
the colorant by shaker; in that case, too many bubbles are produced and they will affect the accuracy
 The maximum capacity of canister is 1.8/3.8Lnotice that the colorant must not be filled above the
uppermost mark of stirring device.
 The machine has good distribution before leaving factory. See Service.exe in the bin file of the installation
catalog; with the instruction of Software Manual, and please assign the colorants to respective canisters if it
is necessary to change.
 The left side of the machine is default side for adding the colorant.
 Open maintenance, choose the colorant code, click “add colorant” to add corresponding colorant, please
ensure the colorant names in the software match the colorant of the canisters.
 Open the top cover. The canisters are pasted with sequential labels corresponding to the colorants.
 Open the cover of the canister and insert the stirring ruler, and then the colorant can be poured into canister
along the stirring ruler. Be careful not to pour the colorant out of the canister. Cover the canister cover when
you finish adding the colorant. When the top cover is opened, machine will not rotate.
 Add the actual corresponding colorant quantity
in the adding colorant interface, and click “add”.
 Rotate the canisters and add the corresponding
colorant in the other canisters.
 Click the stir to stir the colorant
6
6
.
.
4
4
E
E
m
m
p
p
t
t
y
y
i
i
n
n
g
g
P
P
u
u
m
m
p
p
● Air in the pump affect the accuracy, so emptying the air in pumps is a must
● Lift the piston pole and then press it to the bottom and repeat for 4-5 times. Turn the valve rod from horizontal
to vertical position. If there is no colorant dropping from the valve rod, it means the pump is emptied. Then
turn the valve rod to horizontal position. If any colorant drops, turn the valve rod to horizontal position. Lift
