A2 Automatic Dispenser V3.0 12
8. Maintenance
Routine maintenance is needed to ensure that the machine remains in good working condition and has a long
service life. Maintenance and any repairs should only be carried out by qualified personnel.
8.1
D
D
a
a
i
i
l
l
y
y
M
M
a
a
i
i
n
n
t
t
e
e
n
n
a
a
n
n
c
c
e
e
 Add colorant in time when software shows low colorant warning
 If the colorant in the canister is too little, less than 0.5L，which will affect
the accuracy of the dispensing. Then cover the canister lid
 Keep machine power on; even it is not used.
8.2 Periodical Maintenane
Do the following maintenance every 1-6 months：
 Check stirring paddle inside each canister, see whether it works; if not, repair.
 Lubricate screw and guiding rod in every six months
 If the machine has not been used over one week, it shall be powered on and recirculate it automatically
before usage.；
9. Replacing Spare Parte
1）Replacing Outer Canister:
Loose the three screws which fix the canister on the turntable using screwdriver, and then drive the canister
anticlockwise to take off the canister.
2） Replacing Inner Canister：
a. If you want to replace the inner canister, you will take off the outer canister first.
b. Remove the screw on the bracket to fix the canister, pull out the bracket for 10mm. Pay attention to not to
pull out the bracket too much to avoid the colorant leaking off the canister.
c. Rotate the canister anticlockwise, the canister can be taken off the turntable
Fig8.2.1
Screw
Guide Pin
