17
Hang the TV onto the arm assembly
06
by hooking the top support
on TV bracket
04
as shown.
1
HANG YOUR TV
HEAVY! You may
need assistance
with this step.
10
To lock the TV onto arm assembly
06
, install the securement
screw
10
on the TV bracket
04
.
Always make sure your securement screw
10
is tightened, so
the TV is securely fastened to the arm assembly
06
.
CAUTION: Avoid potential personal injury or property damage!
2
SECURELY TIGHTEN
04
06
06
04
11
To Next Page
