Sanus BSF316 - Adjustments; Level Adjustment; Tilt Adjustment

19
1. Loosen screw
10
.
2. Level your TV with
screw
L
.
3. Tighten screw
10
.
Your TV should adjust easily when moved, then stay in place.
Adjust the tilt tension knobs
T
if your TV naturally tilts up or down.
NOTE: If you do not intend to adjust the tilt for different viewing
locations, you can tighten the tilt tension knobs
T
, to prevent
unwanted movement. If needed, use hex key to tighten more firmly.
L
T
1 2 3
Adjustments
11
10
11
10
11
LEVEL ADJUSTMENT TILT ADJUSTMENT
CAUTION:
Screw
10
MUST be
loosened before STEP 2.
