15
3
4
3. Remove the wall plate template
15
and insert three concrete anchors
18
.
CAUTION: Be sure the anchors are seated flush with the concrete surface.
4. Install the wall plate
16
using three lag bolts
17
and washers
19
. Tighten all lag bolts only until the washers are pulled firmly against
the wall plate.
CAUTION: Improper use could reduce the holding power of the lag bolt. DO NOT over-tighten the lag bolts.
18
19
17
16
