Sanus Simplicity SMF3 - Step 3: Hang TV onto Wall Plate

16
3
2
1
HEAVY! You may need assistance with this step.
STEP 3 Hang TV onto Wall Plate
1. Position the arm of wall plate
16
so the elbow is pressed against the wall. Tighten the arm tension screws using hex key
20
to prevent
the arms from moving while installing the TV.
2. Hang the TV onto the arm of wall plate
16
by first hooking the top support, then resting the TV into place.
3. Lock the TV to the wall plate
16
with one screw
21
using hex key
20
.
Top Support
Arm Tension
Screws
20
21
16
20
16
16
