Sanus Simplicity SMF3 - Step 1: Attach TV Bracket to TV; Measure TV Hole Pattern and Assemble Bracket

8
B
A
STEP 1 Attach TV Bracket to TV
These smaller hole patterns only use TV bracket
01
.
Discard the extensions
02
and
03
and screws
04
.
Assemble extensions
02
and
03
onto TV bracket
01
as shown.
Secure using eight screws
04
in the corner holes and hole pattern "1."
75 x 75
100 x 100
200 x 100
200 x 200
300 x 300
400 x 400
01
01
03
200
400
300
100
75
200
100
75
400
300
1-1 Measure Your TV Hole Pattern
1-2 Assemble Your TV Bracket
Measure the width and height of your TV hole pattern in mm.
Record your measurements:
Determine which TV bracket configuration to use, A, B, C, D or E based on your TV hole pattern measurements.
0302
02
75 mm = 7.5 cm = 3 in.
100 mm = 10 cm = 4 in.
200 mm = 20 cm = 7 7/8 in.
300 mm = 30 cm = 11 3/4 in.
400 mm = 40 cm = 15 3/4 in.
cm
inches
x Height
Width
mm mm
inch dimensions approximate
02
03
04
21
04
