1. Specifications
MODEL No. XH2442
Source 230 - 208 VAC / 1 phase / 60 Hz
Remote controller (Option) RCS - SH80UA, WL
Controller P. C. B Ass'y CR - TH2442
Control circuit fuse 250 VAC, 3 A
Fan (Number … diameter) in. (mm) Turbo (1…17-7/16 (443))
Fan motor
Model SFG6X - 41D6P
Source 230 - 208 V / 1 phase / 60 Hz
No. of pole … r.p.m. (230 V, High) rpm 6 … 464
Nominal output W 40
Coil resistance Ω BRW - WHT : 170.3 , ORG - YEL : 43.2
(Ambient temperature 68 °F) WHT - VLT : 18.1 , WHT - PNK : 83.5
VLT - ORG : 43.2 , YEL - BLK : 60.2
Safety device
Operating temperature Open °F266± 14.4
Close °F 174.2 ± 27
Run capacitor VAC, µF 440 V , 4.5 µF
Electronic expansion valve
Coil DKV - MOZS726E
Coil resistance (at 20°C) Ω ORG - GRY : 46 , YEL - GRY : 46
RED - GRY : 46 , BLK - GRY : 46
Valve body IKV - 24D18
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows … Fins per inch 2 … 14.9
Face area ft.
2
(m
2
) 3.69 (0.343)
Panel
Model No. PNR - XH2442
Auto louver motor MT8 - 3C
Auto louver motor … Rated V, W, rpm 240 VAC , 3 W , 3 rpm
Coil resistance (Ambient temperature 77 °F) Ω 16.430 Ω ± 8 %
DATA SUBJECT TO CHANGE WITHOUT NOTICE
1-2 Major Component Specifications
(A) Indoor Unit
