4 User menu setup before leaving factory
Enter into page “LOCK” of user menu, select submenu item “Restore Factory Default” to preset
items before leaving factory as below:
a) Clear out all programs information;
b) Clear out information of parental control (VCHIP);
c) Default setup of user analog data;
d) Set Menu Language as English;
e) Set Power on MODE as Off.
5 Instruction of factory software burning as Table 6
Table 6 Instruction of factory software burning
No. Part No. Part type
Instruction of
software
function
Burned
before
SMT
Burning method
N111 5272564002 EN25Q64-104HIP FLASH Yes
burned with program
ALL11, write-protect setup,
refer to Note 1 in detail
N108 5272404002 AT24C04 HDMI KEY Yes
burned with program ALL11
NA04 5272402002 AT24C02 HDMI EDID Yes
burned with program ALL11
NA05 5272402002 AT24C02 HDMI EDID Yes
burned with program ALL11
NA06 5272402002 AT24C02
HDMI EDID
(supporting
the 3rd HDMI)
Yes
burned with program ALL11
N106 5272402002 AT24C02 VGA EDID Yes
burned with program ALL11
Note 1: Write-protect setup method
Enter into burning interface of
program ALL-100, select item “Config”, press item “config
Setting”, set item “Protect” as “All Protect”; be sure to select item “Config” before burning
software, and write-protect must be re-set after burning program ALL-100 startup every time.
Note 2: Burning and upgrading software method with burning tool ISP
