14
Mechanical Disassembly
(一) Lid Back Removal
Remove screws A and B, Take the Lid Back off.
(A: 2pcs, B: 3pcs)
A
LID
BACK
Picture 1.
A
B
B
B
POWER BOARD
MAIN
BOARD
Picture 2.
