IC Block Diagram and Instruction
1、 Main chip MSD209GL:
GENERAL DESCRIPTION
The MSD209GL is a highly integrated controller IC for LCD/PDP DTV applications with
resolutions up to full-HD(1920 x 1080). It is configured with an integrated triple-ADC/PLL,
a multi-standard TV video and audio decoder, amotion adaptive video de-interlacer, a
scaling engine, the MStarACE-3 color engine, an advanced 2D graphics engine, a
transport processor, a high-definition (HD) MPEG video decoder, a high-definition (HD)
