Sanyo MDF-192 - Performance Specifications

3
㩷
Item MDF-193/192(N)
Self diagnosis function
In the event of any abnormality occurred among temp. sensor and
comp. protect sensor, error code and chamber temperature are
alternately displayed.
zALARM lamp blinks, remote alarm activates and intermittent
buzzer tone is emitted.
Alarm resume function
The alarm buzzer is silenced by pressing alarm buzzer stop key
(BUZZER)
The buzzer will be activated again after certain suspension if the
alarm condition is continued.
Compressor protection Internal thermostat
㩷
㩷
ŶPerformance specifications
Cooling performance
Center point of freezing chamber; -86㷄䋨AT30㷄, no load䋩
Temp. control range
-50㷄䌾-86㷄䋨AT30㷄, no load䋩
220VAC, 50Hz 220VAC, 60Hz 230VAC, 50Hz 240VAC, 50Hz
Rated power consumption
320W 400W 350W 370W
Noise level 46 dB (A) (background noise; 20dB)
Maximum pressure 3.20 MPa
Alarm duration 9 hours
Note: Specifications will be subject to change without notice.
