Sanyo MDF-192 Service Manual

5
Cooling unit parts
<MDF-193/192(N)>
Item Specifications
Compressor
220V, 60Hz
220~240V, 50Hz
Type: C-1RN45L6A Compressor code: 802 021 16
Type: C-1RN45L5A Compressor code: 802 022 15
Refrigerant oil
Ze-NIUSL22SA
Charged q’ty: 230 cc
Cooling system
Forced air cooling㧔partially㧕and DSH
Condenser
Type Finless tube type (8 columns x 2 lines)
Cascade condenser
Pre-condenser 7 columns x 1 line W 290mm
Frame pipe
Ǿ4.76mm x T0.7
Evaporator
Type
Tube on sheet sharing with interiorǾ7.94 mm x T 0.7 mm
Capillary tube (Cascade condenser) (Lower) (Ex)
Resistance
PSI࡮kg/cm
2
9kg/cm
2
6kg/cm
2
34PSI
Length (mm) 2000 2000 500
Outer diameter (mm)
Ǿ1.8 Ǿ1.8 Ǿ2.4
Color None Black None
Refrigerant Type : MU-N49
Composition R-245fa/R600 230g
R-23 110g
R-14 50g
Dryer
Dry core (D-SM032T)㨯㨯㨯Specially dehydrated
Condensing fan
4 blades, Ǿ196mm Material: ABS resin
Condensing fan
motor
Type: SE4-D041N5P Output: 4W
* Refrigerant for service
MU-N49 (EU) ········· For Europe
MU-N49 (DOT) ······ For U, S, A
MU-N49 (J) ············ For other

