6
Refrigeration Circuit
Capillary tube
Cascade condenser
Evaporator
shunt
Capillary tube
Check valve
Capillary tube (EX)
EX tank
Compressor
Pre-condenser
Pre-condenser
Accumulator
Condenser
Frame pipe
Note : Ensure to charge gas from the charging point at EX tank.
× • • • • Point to pull vacuum
