Front
o
q w y i
Back
qProjection Lens (Option)
wIndicators
e Infrared Remote Receiver (Front)
rHandle
t Adjustable Feet
y
Side Control
u Terminals and Connectors
i Main On/Off Switch
o Power Cord Connector
!0 Lamp Cover
!2
CAUTION
Hot air is exhausted from the exhaust
vent. Do not put heat-sensitive objects
near this side.
Part Names and Functions
!0
✽Kensington Security Slot
This slot is for a Kensington lock used to
deter theft of the projector.
* Kensington is a registered trademark of ACCO Brands
Corporation.
✽
!1Infrared Remote Receiver (Rear)
!2
Air Intake Vent
!3 Air Filter Cover
!4 Exhaust Vent
t
!1
!4
!3
