-16-
■ Setting the fixed data
(1) Receive the good quality signal.
(2) Enter the Service Mode
(3) Confirm fixed data to be same as data table. If it is different, change to
correct data.
(4) Return to the Normal Mode
This adjustment is controlled by the Sub CPU (IC801) thorough the IIC Data Bus Line in the chassis, and
those adjustment data are memorized into the memory IC (IC804). Therefore, SUB CPU Board or the
memory IC (IC808) is replaced, data of those will be disappeared. Readjustment should be made. Initial
data is provided in the CPU ROM ,when memory IC (IC804) is replaced with new one, CPU ROM data is
loaded into the memory. (Data list will be shown in previous 5 pages.) Initial data is provided to operating
the monitor basically. For operating the monitor quality performance, further adjustment required following
chassis electrical adjustment.
■ White Balance Adjustment
Pattern : White Pattern
Condition : Screen Size : FULL, Picture Image Level : STANDARD
Adjustment : Enter the service mode, select item No. 111 [ Red ], 112 [ Green ] or 113 [ Blue ]
(White:PC), and adjust a proper white balance.
Note : After adjustment, confirm white balance again by normal picture.
Adjustment
To Next Page
